SEAFOREST Characteristics of flexible solar panels Apr 08, 2025

SEAFOREST Characteristics of flexible solar panels

1. Flexible & Ultra-Lightweight:

- Bendable design

- Optimized composite materials weighing ≤3kg/m²

2. Elegant Aesthetics & Easy Installation:

- Original sleek design without flare effect

- Significant cost savings in transportation and installation

3. Customizable Solutions:

- Supports customization with high added value

4. Superior Low-Light Performance:

- Enhanced power generation under dawn, dusk, and cloudy conditions

5. Proprietary Lightweight High-Strength Fiber Composite (Self-Developed) - Polymer Chain Modification Technology:

- Light transmittance ≥91% (surpasses similar products)

- No photoelectric conversion barrier

- Superior waterproofing & UV resistance

- 25-year power output guarantee

- Data Backed: 20-year outdoor polymer material data + 20,000hr accelerated aging tests (yellowing index Δ≤3)

6. Resin-Fiber Interface Reinforcement Technology:

- Modulus up to 1,300MPa (100% higher than conventional products)

- Eliminates hidden cell cracks

7. Nano-Hybrid Flame Retardant Technology:

- Meets: Building Class B1 & UL94-V0

- EN45545 (EU) / TB/T3237 (China Railway) flammability standards

8. Salt Corrosion Resistance:

- Polymer materials withstand salt spray erosion

9. Certified Reliability (Passed):

- IEC61215: Damp Heat Test: Long-term moisture resistance; Hail Impact: 25mm ice ball at 23m/s ; Hot Spot Endurance

- IEC62716: Ammonia corrosion resistance

- IEC60068: Dust/sand resistance

- IEC61730: Fire resistance; Extreme temperature adaptability

Product List：

JP-AC Model	SF-520M-FL	SF-400M-FL	SF-200M-FL
Maximum power output (Pmax) W	520	400	200
Maximum power operating voltage (Vmp) V	40.24	31.2	15.50
Maximum power operating current (Imp) A	12.94	12.84	12.95
Open circuit voltage (Voc) V	48.10	37	18.30
Short circuit current (Isc) A	13.62	13.56	13.75
Module conversion efficiency %	19.5	19.5	18.6
External dimensions	224611852.5mm	188310922.5mm	91811702.5mm
Weight	7.5KG	6.0KG	3.3KG
